VT800-L 4G Truck GPS Tracker
Product Description:VT800-L is a 4G based GPS vehicle tracker. With built-in high-precision GPS positioning module reports the vehicle location and vehicle status to the vehicle tracking service platform through the 4G network for real-time monitoring, anti-theft and scheduling management of the vehicle. It can be applied to fleet management, public transport management, school bus management, taxi operation management, vehicle insurance management, lease management and private car anti-theft, etc. With built-in 128Mb Flash memory. VT800-L will automatically save historical in blind area and resend it to server once signal is restored. VT800-L contains an RS232 port that can be connected to RFID or ibutton for vehicle driver identification and vehicle control. It can also be connected the OBD decoder to read the car ECU data and connect other RS232 peripherals to achieve the corresponding function.
Detail:
 |
4G CAT4
Full Network Compatibility. |
 |
GPS/BDS/QZSS
Multiple positioning systems for high-precision real-time positioning. |
|||
 |
Fuel Monitor
Support Capacitive/ultrasonic fuel sensor for fuel monitoring. |
 |
500mAh Internal Battery
Built-in 500mah polymer lithium battery. |
|||
 |
Dual Server IP
Support uploading location data to two servers simultaneously. |
 |
Tamper Alarm
If the car drives over that circle, the server will send the warning to the device automatically. |
|||
 |
128Mb Flash Memory
Store buffer when the signal is lost to keep a complete tracking route. |
 |
Temperature Monitor
Keep fresh transportation of the cold chain, and support 8 temperature sensor at the same time. |
|||
 |
Driving Behavior Monitor
Support harsh acceleration alarm, breaking alarm, harsh turning alarm, speeding alarm, drunk driving alarm, etc.. |
 |
Multiple I/O
2RS232+2AD+3IN+2OUTPUT+1-wire+speaker + Microphone
|
|||
 |
Listen-In
Allows the caller to listen to what is happening around the tracker.
|
 |
Two Way Audio
With MIC and speaker, it’s easy to realize voice-monitor or two-way audio. |
Features:
VT800-L is a 4G based GPS vehicle tracker. With built-in high-precision GPS positioning module reports the vehicle location and vehicle status to the vehicle tracking service platform through the 4G network for real-time monitoring, anti-theft and scheduling management of the vehicle.
It can be applied to fleet management, public transport management, school bus management, taxi operation management, vehicle insurance management, lease management and private car anti-theft, etc.
With built-in 128Mb Flash memory. VT800-L will automatically save historical in blind area and resend it to server once signal is restored.
VT800-L contains an RS232 port that can be connected to RFID or ibutton for vehicle driver identification and vehicle control. It can also be connected the OBD decoder to read the car ECU data and connect other RS232 peripherals to achieve the corresponding function
Specification:
| Case | Size 72*61*24mm |
| Power Supply | 11.4~100V Input, low power outage protection, red/black wire |
| IN1 | Default negative trigger, software configurable positive and negative trigger |
| IN2 (ACC Detection) | Positive trigger by default, positive and negative trigger can be configured by software |
| IN3 | Positive trigger by default, positive and negative trigger can be configured by software |
| AD | Default AD input, software configurable positive, negative trigger and AD input (0-36V) |
| Output Port | Open drain output, driving capability greater than 500MA |
| 1-wire Interface | Digital, iButton or temperature interface |
| RS232 | Can be connected to RFID, oil sensor, magnetic card reader, camera, OBD |
| Micphone | External MIC, two-way conversation |
| Speaker | External Speaker, two-way conversation |
| MCU | Cortex-M4，AT32F415RBT7 |
| Battery | 500mAh, high temperature battery |
| 4G Communication Module | VT800-LACN：（EC200A-CN）
LTE-FDD: B1/B3/B5/B8 LTE-TDD: B34/B38/B39/B40/B41 WCDMA: B1/B5/B8
VT800-LUEU：（EC200U-EU） LTE-FDD: B1/B3/B5/B7/B8/B20/B28 LTE-TDD: B38/B40/B41 GSM: 850/900/1800/1900MHz
VT800-LAAU：（EC200A-AU） LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66 LTE-TDD: B40 WCDMA：B1/B2/B4/B5/B8 GSM: 850/900/1800/1900MHz
|
| GPS Module | L76K（GPS+BD）Dual-mode positioning |
| Flash Memory | 128M bit |
| Sensor | 3D acceleration sensor |
| GSM Antenna | External extension antenna |
| GPS Antenna | External extension with antenna |
| Switch | External shrapnel switch |
| SIM Card | Micro SIM Card |
| Debug Port | Micro USB |
| Indicator | 1 blue and 1 green LED indicator light each |
| Protocol | Istartek new Protocol |
